Black - wire 1
Arrow Global BLE
Self-install
quick start.
Three-wire installation guidance for competent automotive electrical installers.
Before you begin
This guide is a quick reference, not a substitute for vehicle-manufacturer requirements, site rules or applicable electrical and workplace safety practices. If you are unsure, arrange installation by ACCER.
Standard installation
Three connections.
Constant power, chassis ground and ignition input support normal vehicle tracking, accurate trip starts and idling reports.
- 01
Record the device serial / IMEI and customer asset details.
- 02
Verify constant power, ignition and ground quality with a multimeter.
- 03
Avoid ABS, airbag, brake and other safety-critical circuits.
- 04
Choose a hidden, serviceable location with a practical GPS view.
- 05
Protect wiring from sharp edges, heat, vibration and moving parts.
Basic wiring
Connect and protect.
Insulate joins, strain-relieve the harness and secure the device before handover.
Red - wire 2
Constant power
10-30 VDC; protect with a 3A fuseWhite - wire 3
Ignition input
Switched ignition; protect with a 3A fuseAfter installation
ACCER commissions the tracker.
Send ACCER the device serial / IMEI and the vehicle or asset details. ACCER will confirm connectivity, GPS position, ignition and power status in AM Tracking / Telematics Guru.
Installer access
Scan for this guide.
Use this QR code on packaging, job cards or installation paperwork. It points to the permanent ACCER website address for this guide.
